ELECTRICAL SWITCHES ELECTRONIC PROXIMITY SWITCH

$230.00
Tax included Shipping excluded
AESPR08
Quantity
Last items in stock

Estimate shipping cost

Submit



Fast delivery - Australia wide service



Warranty - 1 year



100% - Australian owned

SWITCHES ELECTRONIC IFM PROXIMITY SWITCH

Operating voltage [V]10...30 DC; ("supply class 2" to cULus)Current consumption [mA]< 10Protection classIIIReverse polarity protection yes Outputs Electrical designPNPOutput function normally openMax. voltage drop switching output DC [V]2.5Permanent current rating of switching output DC [mA]200Switching frequency DC [Hz]5000Short-circuit protection yesType of short-circuit protection pulsed Overload protection yes Sensing range [mm]60; (referred to magnet M 4.0)Response sensitivity [mT]1.2Accuracy / deviationsHysteresis [% of Sr]1...10Operating conditionsAmbient temperature [°C]-25...75ProtectionIP 67
Description Proximity Sensor
Warranty 1Y
Overall Length
Thread
Weight .14kg
Gauge Range Not Applicable
Item Type Proximity Sensor
Sender Type Proximity
Terminal Style Operating voltage [V]10...30 DC; ("supply class 2" to cULus)Current consumption [mA]< 10Protection classIIIReverse polarity protection yes Outputs Electrical designPNPOutput function normally openMax. voltage drop switching output DC [V]2.5Permanent current rating of switching output DC [mA]200Switching frequency DC [Hz]5000Short-circuit protection yesType of short-circuit protection pulsed Overload protection yes Sensing range [mm]60; (referred to magnet M 4.0)Response sensitivity [mT]1.2Accuracy / deviationsHysteresis [% of Sr]1...10Operating conditionsAmbient temperature [°C]-25...75ProtectionIP 67
New product
AESPR08

Cross Reference

MS5011
